Product Description
This foam has 100% open cells made by thermal reticulation process. The foam blocks are placed inside high pressure reticulation chamber for charging with gas to convert it in different PPI (pores per linear inch) depending upon the customer needs.
Ester based Reticulated Foam are stable with petroleum products and thus can be used effectively to mop-up and filter petroleum products
Ether based Reticulated Foam are not affected by water and thus are ideal for water filtration
Ester based automotive filters are technically superior than paper filters in terms of efficiency, life as well as reusability
Grades | Density (Kg/m3) | Tensile Strength (Kgf/cm2 ) | Elongation % | Hardness (Kgf/323cm2 @ 50%) | Resileance % |
R28/80 | 28 ±3 | >=1.8 | >=300 | 30 ±4 | >=22 |
R28/40 | 28 ±3 | >=1.0 | >=300 | 26 ±4 | >=20 |
R28/30 | 28 ±3 | >=1.0 | >=200 | 30 ±4 | >=20 |
R28/20 | 28 ±2 | >=1.0 | >=200 | 30 ±4 | >=20 |
S28/80 | 28 ±2 | >=1.8 | >=300 | 30 ±4 | >=22 |
N40/40 | 40 ±2 | >=1.0 | >=110 | 64 ±4 | >=36 |
MAJOR APPLICATIONS
- Filtration and Pre-Filtration of Air Oil and Water
- Ceramic Foam Filters
- Outdoor Furniture
- Microphones and Headphones
- Safety Fuel Tanks
- Ink Cartridges
